Three-layer sintered mesh for demanding process filtration
Engineered with a protective outer wire mesh, a micro-aperture control layer, and a rigid structural support mesh. Diffusion-bonded under high temperature and vacuum to eliminate wire displacement, fiber shedding, and structural distortion under cyclic delta-P.
Solid-state vacuum diffusion bonding (1150°C)
AISI 316L (1.4404) / AISI 304
1.20 mm – 1.80 mm (±0.05 mm)
-200°C to +480°C continuous
Surface Guard & Pre-separation
Precision Micron Rating
Rigidity & Fluid Dispersion
Provides the rated pore opening and particulate retention efficiency with non-deforming pore geometry under pressure.
Chemical & Polymer
Ideal for resin filtration, monomer cleanup, and high-temp polymer dope processing.
Backwash Cleanability
Smooth pore geometry allows ultrasonic, thermal pyrolysis, and reverse liquid flushing.
Custom Fabrication
Delivered as flat sheets, disc packs, pleated leaves, welded tubes, and custom cones.
Alloy Availability
Standard 316L, 304L, 904L, plus Hastelloy C-22/C-276, Inconel 600, and Monel 400.
3-layer sintered mesh technical specifications
Vacuum diffusion bonded composite structures engineered for high differential pressure, stable pore retention, and repetitive backwash cycles.
2 µm – 100 µm
Absolute & nominal retention1.70 mm
Calibrated uniform cross-section-200°C to +600°C
Continuous thermal enduranceDiffusion Bond
Solid-state molecular fusionLayer structure & bonding architecture (3-layer composite)
Control Layer (Fine Mesh)
Precision particle retention and calibrated pore aperture
Protection Layer (Buffer)
Prevents mechanical abrasion and stabilizes micro-geometry
Reinforcement & Drainage Layer
Provides mechanical rigidity and uniform flow distribution
Comprehensive engineering parameter matrix
| Parameter (EN & Bilingual) | Standard Value | Test Standard | Tolerance |
|---|---|---|---|
Filtration Rating (Micron) | 2 µm – 100 µm (Nominal & Absolute) | ISO 4572 / ASTM E128 | ±5% at rating point |
Standard Thickness | 1.70 mm (custom: 0.8 mm – 3.5 mm) | DIN 53105 / ISO 534 | ±0.05 mm |
Operating Temperature | -200°C to +600°C (-328°F to +1112°F) | Continuous in oxidizing media | Up to 800°C inert |
Layer Construction | 3-Layer composite (Control + Protection + Support) | EN 10204 3.1 Certified | Exact alignment |
Bonding Process | Vacuum Solid-State Diffusion Sintering | AWS D10.12 / ASTM B528 | Zero binder residue |
Standard Alloy Material | AISI 316L (1.4404) & AISI 304 (1.4301) | ASTM A240 / DIN EN 10088 | Dual certified |
Max Differential Pressure | Delta P = 3.0 MPa to 10.0 MPa collapse | ISO 2941 Verification | Design dependent |
Standard 3-layer model selection table
| Model | Nominal Rating | Absolute Rating | Thickness | Air Permeability | Bubble Point |
|---|---|---|---|---|---|
| MF-3L-005 | 5 µm | 12 µm | 1.70 mm | 450 L/m²/s @ 200Pa | ≥ 6.8 kPa |
| MF-3L-010 | 10 µm | 20 µm | 1.70 mm | 820 L/m²/s @ 200Pa | ≥ 4.5 kPa |
| MF-3L-025 | 25 µm | 40 µm | 1.70 mm | 1,450 L/m²/s @ 200Pa | ≥ 2.6 kPa |
| MF-3L-050 | 50 µm | 75 µm | 1.75 mm | 2,200 L/m²/s @ 200Pa | ≥ 1.4 kPa |
| MF-3L-100 | 100 µm | 140 µm | 1.80 mm | 3,600 L/m²/s @ 200Pa | ≥ 0.8 kPa |
Require custom alloy laminates or specific test certificates?
MutualFilter produces custom layered laminates in Alloy 20, Hastelloy C-22/C-276, Inconel 600/625, and Monel 400 with 3.1 Material Test Reports.
Proven applications for 3-layer sintered mesh
Standard 3-layer laminates combine a protective outer mesh, a precision filtration control layer, and a rigid structural support layer to withstand aggressive temperatures and high mechanical loads.
Technical Operating Envelope
Application Advantages
- Rigid pore matrix prevents wire migration
- Repeated ultrasonic & backwash cleanability
- Seamless welded seams for candle filters
Require custom sintered mesh dimensions or special alloys?
We manufacture custom 2-layer to 8-layer sintered laminates, perforated plate backed composites, and calendered pore structures to your drawing specifications.
