Engineered stainless steel filter nozzles for rigorous media retention
MutualFilter manufactures custom wire mesh and wedge-profile filter nozzles designed for uniform liquid collection, low pressure drop, and non-clogging performance in industrial vessels.
Robust welded construction engineered to withstand high backwash pressures and thermal fluctuations without media loss.
Critical filtration applications
Tailored aperture geometries configured for process vessels and bed distribution.
Water & Wastewater Treatment
Media retention in ion exchange resin columns, rapid sand filters, and carbon bed contactors.
Chemical & Petrochemical
Corrosion-resistant distribution and collection in acid tanks, reactor bottoms, and catalyst beds.
Power & Thermal Processing
High-temperature condensate polishing, boiler feedwater purification, and cooling tower loops.
Filter nozzle engineering specifications
Review slot aperture tolerances, flow metrics, alloy grades, and vessel underdrain compatibility for industrial water treatment and process vessels.
Two-point contact prevents particle wedging and allows rapid backwashing without blind spots.
Wedge profile wire is fully fusion-welded to support rods at every single junction for high burst resistance.
Standard units withstand collapse differentials exceeding 10 bar (145 psi) without slot distortion.
Electro-chemical pickling removes free iron and restores chromium oxide passivation for maximum longevity.
| Model code | Slot aperture | Open area | Nominal flow | Thread / fitting | Screen dia. | Primary vessel type |
|---|---|---|---|---|---|---|
| FN-V100-STD | 0.20 mm (200 µm) | 18.5% | 1.2 – 2.5 m³/h | 3/4" NPT / BSP | 55 mm | Ion exchange & water softening |
| FN-V125-MED | 0.25 mm (250 µm) | 22.4% | 2.5 – 4.2 m³/h | 1" NPT / BSP | 65 mm | Sand filters & granular media |
| FN-V150-PWR | 0.50 mm (500 µm) | 28.0% | 4.5 – 8.0 m³/h | 1-1/4" NPT / BSP | 80 mm | Carbon bed & coarse pre-filtration |
| FN-DL200-DBL | 0.15 mm (150 µm) | 15.2% | 3.0 – 6.5 m³/h | 1-1/2" NPT / Flanged | 100 mm | Condensate polishing & mixed bed |
| FN-ST300-MAX | 0.10 mm (100 µm) | 12.8% | 5.0 – 11.0 m³/h | 2" NPT / Custom Hub | 120 mm | High-pressure chemical reactor underdrain |
Need custom slot openings or non-standard vessel threading?
Our engineering team builds custom filter nozzles, header lateral systems, and media retainers machined precisely to your vessel drawing specifications.
Filter Nozzle Operating Environments
Engineered for high mechanical rigidity and uniform hydrodynamic distribution across demanding water filtration, demineralization, and chemical processing media beds.
Water Treatment & Sand Filter Underdrains
Engineered for municipal and industrial gravity/pressure sand filters, granular media vessels, and dual-media filtration beds.
Uniform distribution across entire bed surfaces prevents dead zones, channeling, and backwash media loss.
Resistant to abrasive sand particle scouring and cyclic hydraulic backwash shock loads.
Ion-Exchange & Softening Resin Columns
Precision slot tolerances down to 0.10 mm ensuring complete retention of fine cation/anion exchange resin beads under high velocity.
Continuous non-clogging wedge wire profile eliminates resin migration into downstream pure water circuits.
Passivated alloys withstand aggressive acid (HCl/H2SO4) and caustic (NaOH) regeneration chemical cycles.
Activated Carbon & Catalyst Retention
Robust double-head and long-stem nozzle assemblies for high-temperature chemical reactors, carbon adsorption, and gas scrubbing columns.
Robust welded structural integrity sustains high differential pressure during intense backflush sequences.
Custom threaded, flanged, or quick-release mounting stems engineered for rapid turnaround during plant shutdowns.
Need Custom Nozzle Slot Openings or Stem Fittings?
From bespoke slot openings and high-flow double-head configurations to specialized metallurgy for aggressive process fluids, our engineering team manufactures custom filter nozzles built to your exact vessel schematics.
Standard BSP, NPT, M20–M36 metric threads, or customized weld-plate lockings.
Continuous V-wire gap consistency verified by optical laser metrology.
Complete EN 10204 3.1 material certificates and hydrostatic pressure test logs.
Ready to specify precision filter nozzles for your vessel or strainer?
Configure custom wedge wire filter nozzles with slot tolerances down to 20 microns. Fabricated in 304, 316L, 904L, and Hastelloy alloys with standard BSP/NPT threads or custom flange connections to meet your flow distribution requirements.
Slot sizing to 20 µm
Precision continuous V-wire slots with continuous welded stability.
MTC 3.1 certification
Full heat numbers and material test traceability for 316L, 904L, and Hastelloy.
Pressure certified
Hydrostatic burst and collapse testing reports provided per vessel spec.
24-hour engineering quotes
Direct review by metallurgical engineers with technical drawings included.
