Engineered Multi-Ply Filtration Structures
6+ layer sintered wire mesh laminates
Vacuum-sintered multi-layer wire mesh combined with rigid perforated plate or reinforcement mesh. Built to endure heavy delta-P spikes, repeated backwashing, and abrasive solid-liquid separation.
6-Layer laminate anatomical stack
Protective layer
Square Mesh 20–50 Mesh
Precision filtration layer
Dutch Weave 1 µm – 100 µm
Dispersion buffer layer
Plain Weave 60–100 Mesh
Primary reinforcement layers
Coarse Square Mesh 12–20 Mesh
Heavy drainage base / Plate
Perforated Sheet or 8–10 Mesh
Multi-layer sintered mesh technical specifications
Review structural configurations, micron ratings, temperature limits, and alloy compatibility for standard 5-layer and custom sintered laminates.
1 µm – 200 µm
Pore stability under load-200°C to +650°C
Cryogenic to high-tempUp to 50 bar (ΔP)
High mechanical stabilityUp to 1200×1500mm
Custom discs & tubes availableMicron Rating (µm) Nennfeinheit (Porengröße) | Layer Setup Lagenaufbau | Thickness (mm) Nenndicke (±0.05) | Air Permeability Luftdurchlässigkeit (Δp=200Pa) | Bubble Point Blaspunktwert (Pa) | Unit Weight Flächengewicht |
|---|---|---|---|---|---|
| 1 µm (0.001 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 45 L/dm²/min | ≥ 4200 Pa | 8.5 kg/m² |
| 2 µm (0.002 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 65 L/dm²/min | ≥ 3600 Pa | 8.5 kg/m² |
| 5 µm (0.005 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 120 L/dm²/min | ≥ 2800 Pa | 8.5 kg/m² |
| 10 µm (0.010 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 220 L/dm²/min | ≥ 2100 Pa | 8.5 kg/m² |
| 20 µm (0.020 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 450 L/dm²/min | ≥ 1400 Pa | 8.5 kg/m² |
| 50 µm (0.050 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 980 L/dm²/min | ≥ 750 Pa | 8.5 kg/m² |
| 100 µm (0.100 mm) | 5-Layer Standard | 1.70 mm (±0.05) | 1850 L/dm²/min | ≥ 420 Pa | 8.5 kg/m² |
Custom Multi-Layer Configurations & Material Certifications
All sintered mesh sheets and fabricated elements are delivered with full Mill Test Certificates (EN 10204 3.1), bubble point test records, and PMI chemical analysis.
Where sintered mesh performs best
Multi-layer sintered laminates combine fine micron ratings with rigid structural strength for processes where standard wire cloth collapses or migrates.
Need custom sintered laminate specifications?
Send your operating temperature, media type, micron rating, and differential pressure requirements to our engineering team.
Configure your multi-layer sintered mesh assembly.
Submit your layer requirements, target micron ratings, and operating media. Our filtration engineers calculate delta P limits and return validated CAD drawings within 24 hours.
Custom laminate stacks
Zero particulate shedding
Discs, cones & custom shapes
Corrosion-resistant alloys
