Screening and solid-liquid separation mesh
Precision stainless steel wire mesh engineered for dewatering systems, high-frequency vibratory screens, slurry classification, and continuous filtration equipment. Built for high mechanical loads and exact cut-points.
Separation Performance Specs
Specs SheetPrimary Functions
Dewatering & Slurry Drainage
High open-area square and slotted meshes engineered to accelerate liquid drainage under continuous vibration.
Vibratory Solid-Liquid Separation
Tightly tensioned screen panels and discs with high fatigue resistance for circular and rectangular separators.
Slurry & Particle Classification
Calibrated apertures providing sharp particle cut-points from 20 microns to 10 millimeters without blinding.
Selecting the right wedge wire screen for dewatering
Match your slurry characteristics, slot dimensions, and structural profile to achieve clean liquid-solid separation with continuous non-blinding performance.
Engineering workflow
Define feed & particle profile
Identify solid concentration, nominal particle distribution, and liquid viscosity.
Calculate required slot width & open area
Balance filtration efficiency with pressure drop and hydraulic flow velocity.
Choose wire profile & support rod geometry
Determine mechanical strength against hydraulic collapse and abrasive wear.
Select alloy & surface treatment
Prevent chemical pitting, stress corrosion cracking, and abrasive erosion.
Define feed & particle profile
Accurate slot sizing starts by setting the aperture to 50-70% of the d50 cut point for retention, or sizing for free drainage where cake filtration will develop naturally.
Cut-point particle size (d50), Total Suspended Solids (TSS), Operating temperature
Slot size vs. open area reference
Standard v-wire geometry combinations for liquid filtration and solids dewatering.
| Slot width | Standard wire profile | Calculated open area | Primary separation function |
|---|---|---|---|
| 0.05 mm (50 µm) | 12S (1.2mm width) | 4.0 % | Fine solids retention & micro-straining |
| 0.10 mm (100 µm) | 12S (1.2mm width) | 7.7 % | Secondary dewatering & sand screening |
| 0.25 mm (250 µm) | 18S (1.5mm width) | 14.3 % | Industrial effluent separation |
| 0.50 mm (500 µm) | 22S (2.2mm width) | 18.5 % | Vibratory dewatering & pulp thickening |
| 1.00 mm (1000 µm) | 28S (2.8mm width) | 26.3 % | Coarse mineral slurry & intake screens |
Available screen configurations
Fabricated to fit static gravity chutes, pressurized vessels, or rotating dewatering equipment.
Need validation for an abrasive or custom dewatering feed?
Send your feed volume, solid percentage, particle distribution curve, and chemical conditions for engineer-verified slot and alloy recommendations.
Need custom mesh specifications for your filtration process?
Send us your target mesh count, wire diameter, micron rating, and alloy grade. Our engineering team reviews specifications and provides technical proposals with verified lead times.
Exact aperture tolerances
Manufactured to ASTM E2016 and ISO 9044 industrial standards.
Full alloy traceability
EN 10204 3.1 mill test certificates supplied with every order.
Custom fabrication
Slit coils, stamped discs, cylinder screens, and multi-layer sintered packs.
