Precision Filter Tubes & Cylindrical Screen Assemblies
Engineered from sintered multilayer mesh, wedge wire, and woven wire cloth for critical high-pressure, high-temperature liquid and gas filtration environments.
Filtration Rating
1 µm – 25 mm
Standard Alloys
316L, 304, Hastelloy C-276
Construction
Sintered Mesh, Wedge Wire, Woven Cloth
Joining Tech
Plasma & TIG Precision Welding
Custom flange, threaded end fitting & reinforced internal perforated core available.
Technical Specifications & Standards
MutualFilter precision filter tubes and cylindrical screens are manufactured with reference to ASTM E2016 and ISO filtration standards for process reliability.
Absolute & nominal retention ratings
Seamless & TIG continuous welded
304, 316L, 904L, Inconel, Titanium
Sintered metal thermal stability
Comprehensive Parameter Matrix
Standard manufacturing specs alongside custom engineering thresholds.
| Parameter | Standard Specification | Custom OEM Sizing & Options | Compliance / Standard |
|---|---|---|---|
Outer Diameter (OD)Dimensions | 10 mm – 300 mm (0.39″ – 11.8″) | Up to 1200 mm (47.2″) custom seamless or welded | ISO 2942 / ASTM E2016 |
Overall Length (L)Dimensions | 100 mm – 1500 mm (3.9″ – 59.0″) | Continuous lengths up to 3000 mm or segmented | DIN 24183 |
Filtration Rating (Micron)Filtration | 1 μm – 500 μm (Absolute & Nominal) | Sub-micron membrane support or >1000 μm coarse coarse | ISO 16889 |
Flow OrientationFiltration | Out-to-In (ETI) & In-to-Out (ITE) | Bi-directional reinforced core support | ISO 3724 |
Alloy GradesMaterials | AISI 304 / 304L, AISI 316 / 316L | 317L, 904L, Hastelloy C-22/C-276, Inconel 600, Titanium Gr 2 | ASTM A240 / EN 10088 |
Media ConstructionConstruction | 5-Layer Sintered Wire Mesh / Single Woven Mesh | 3 to 7-layer custom sinter bonds, perforated jacket | ISO 4783 |
Connection TypeEnd Fittings | DOE (Double Open End), SOE with 222/226 O-rings | NPT / BSP threaded, ANSI flanged, quick-clamp hygienic | ASME B16.5 / DIN 11851 |
Collapse PressureMechanical | 10 bar – 50 bar (145 psi – 725 psi) | High-pressure reinforced cores up to 210 bar (3000 psi) | ISO 2941 |
Operating TemperatureMechanical | -50°C to +300°C (-58°F to +572°F) | -200°C to +600°C (-328°F to +1112°F) high-temp seals | DIN 3158 |
Filter Cylinder Media Constructions
Select the appropriate structural matrix based on mechanical load, flow rate, and cleaning cycle requirements.
- Protective layer
- Control layer
- Dispersion layer
- 2x Support layers
- Continuous slot matrix
- Self-cleaning action
- High pressure resistance
- Smooth surface finish
- High dirt holding
- Extended service lifecycle
- Reinforced inner core
- Low pressure drop
Need Non-Standard Sizing or Custom Media Verification?
Our engineering team works directly with OEM filter builders and process plant managers to design, simulate, and verify wire mesh cylinder specifications to fit exact housing drawings.
Engineered Applications & Sector Expertise
MutualFilter supplies precision stainless steel woven wire mesh, filter cartridges, and wedge wire screens custom-tailored for demanding industrial process environments worldwide.
316L, 904L, Alloy 20 & Hastelloy C-276 Woven Mesh
- Corrosion-resistant alloys
- High delta-P structural stability
- Continuous operation to 600°C
5-Layer Sintered Wire Mesh & Rimmed Screen Packs
- High gel-holding capacity
- Minimal pressure drop
- Seamless spot-welded rims
Continuous Slot Wedge Wire & Heavy Dutch Weave
- Self-cleaning V-wire design
- Non-clogging surface geometry
- High flow velocity resistance
Smooth Surface Sintered Dutch Weave 316L
- Electropolished surface finishing
- Zero fiber detachment
- Fully cleanable & steamable
Heavy-Duty Sintered Mesh & Reinforced Wedge Wire
- High collapse strength
- Erosion resistant geometry
- Custom slot & pore dimensions
Custom Woven Mesh & Perforated Core Support
- Precision laser cutting & welding
- Custom end-cap fittings
- 100% material traceability
Require a custom mesh configuration or specialized alloy?
Our engineering team collaborates directly with plant operators and filter OEMs to design custom cylindrical screens, multi-layer sintered packs, and precision slot wedge wire assemblies tailored to your exact drawings.
Certified traceability with AISI 304, 316L, 904L, Inconel, and Hastelloy grades tested for severe corrosion environments.
Multi-layer diffusion bonding, precision laser seam welding, pleated profiles, and bespoke cylindrical core reinforcements.
Differential pressure (ΔP) modeling, nominal-to-absolute micron retention ratings, and open area fluid flow calculations.
Direct OEM print translation, tight dimensional machining tolerances, and full production feasibility validation.
Require Custom Filter Tubes or Cylindrical Screen Assemblies?
Collaborate directly with our filtration engineers to validate diameters, lengths, layer combinations, and end-fitting configurations to your drawings.
