Flexible woven media for filtration, screening and particle separation.
Engineered stainless steel woven wire cloth in Plain, Twilled, Plain Dutch, and Twilled Dutch configurations. Fabricated in AISI 304, 316L, 904L, and specialized nickel alloys for stringent screening, liquid-solid straining, and chemical separation.
Calibrated Looms Engineered for Stringent Retention Limits
At MutualFilter, every square meter of stainless steel woven wire mesh is manufactured on state-of-the-art CNC rapier looms equipped with closed-loop electronic tension control. By eliminating mechanical variance across the entire loom width, we prevent aperture deformation and yield absolute micron retention ratings.
Following precision weaving, all filtration media undergoes multi-stage ultrasonic cleanroom degreasing to remove drawing lubricants and residual particulates, guaranteeing compliance with high-purity pharmaceutical, aerospace, and polymer melt filtration standards.
Tensile Integrity
Precision warp/weft tension calibration eliminates wire slippage and maintains structural rigidity under extreme differential pressure.
Pore Consistency
Strict geometric aperture distribution engineered in accordance with ISO 9044 Class A tolerances for exact particle cutoff.
Chemical Compatibility
High-grade 304, 316L, 904L, and Hastelloy wire stock with cleanroom ultrasonic degreasing for demanding chemical processing.
Real-time optical laser inspection during 316L Dutch weave cycle
Standard & High-Differential Weave Architectures
Engineered weave geometries tailored for optimal mechanical stability, flow coefficient, and micron-level particle separation.
Precision Wire Mesh Specification & Alloy Matrix
Engineered aperture tolerances, weave classifications, and metallurgy for critical filtration, separation, and straining applications across industrial environments.
Standard Industrial Weave Matrix
Click any weave structure to view tolerance alignment
| Weave Type | Mesh Count Range | Nominal Aperture (µm) | Open Area % | Standard Alloys | Standard |
|---|---|---|---|---|---|
Plain Weave (Square Mesh) | 1x1 to 635x635 | 20µm – 25mm | 25% – 85% | AISI 304, 304L, 316, 316L | DIN ISO 4783-2 |
Twilled Weave | 20x20 to 635x635 | 20µm – 1,000µm | 20% – 58% | AISI 316L, 321, 310S | ASTM E2016-20 |
Plain Dutch Weave (PDW) | 8x85 to 80x400 (high-flow up to 165x1200) | 20µm – 310µm | 18% – 42% | 316L, 904L, Hastelloy C-22 | ISO 9044 Class A |
Twilled Dutch Weave (TDW) | 20x250 to 400x2800 | 1µm – 100µm | 12% – 32% | 316L, Alloy 20, Monel 400 | ISO 9044 Class A+ |
Reverse Dutch Weave (RDW) | 72x15 to 400x120 | 15µm – 250µm | 16% – 38% | AISI 304, 316, 316L | DIN 1210 High-Tensile |
Broad Mesh / Five-Heddle | 10x10 to 120x120 | 60µm – 1,500µm | 30% – 65% | 316L, Inconel 600, Hastelloy | ASTM E2016-20 |
Bubble Point Verification
ASTM F316 test protocols correlate absolute micron cut-off ratings with calculated pressure differential curves.
Material Traceability
Positive Material Identification (PMI) spectral analysis and mill test reports available when specified in the order.
Compliance & Standards
Need Tailored Mesh Apertures or Slit Roll Dimensions?
From custom roll widths and narrow slit coils to precision-stamped filter discs and fabricated components. Share your target mesh specifications or drawings for direct engineering review.
Custom roll widths from 10 mm to 2,000 mm with tight edge tolerances.
Single or multi-layer stamped discs, circles, and custom tooling shapes.
Manufactured in conformance with ISO 9044 and ASTM E2016 tolerances.
